RAY Tronic P20 15V/20A Power Source
Powerful stabilised switched-mode power supply Raytronic P20 with adjustable output voltage and current limit is perfect for powering modeller's chargers with power up to 300W and other electronic devices. It is suitable for testing electronic devices that have to be powered by 6–15V DC.
The power supply is equipped with protection circuits that protect it from short-circuit on input or from overloading. There is an active cooling system, which stabilises operating conditions and protects from overheating.
Output voltage and current limit are adjusted via knobs on the front panel - values of output voltage or current are shown on 3-digit LED display (choose between current and voltage via switch).
Thanks to an adjustable output voltage and current limit you can use the power source as a charger for batteries that need constant voltage/constant current charging mode (such as acid-lead or Li-Fe batteries, other than A123® with different chemicals and charging behaviour. Common modeller's chargers specialized for A123® cells can end the charging too soon (or completely ignore the cells) etc.
Specifications:
Input voltage [V] | 220 - 240 |
Channels | 1 |
Output voltage 6 [V] | 15 |
Output current 0 [A] | 20 |
Power [W] | 300 |
Regulated | Ano |
Display | Ano |
Length [mm] | 160 |
Width [mm] | 165 |
Height [mm] | 75 |
Includes:
- Raytronic P20 power supply
- Power cable
- User manual
Robitronic Expert LD 100 Charger LiPo 2-4s 10A 100W
Product information "Robitronic Expert LD 100 Charger LiPo 2-4s 10A 100W"
The Expert LD 100 Charger is a multi-function charger/discharger that allows you to use the most popular battery types such as LiPo/LiHV/Lilon/LiFe/NiCd/NiMH/Pb.
With a remarkable 100 watts of charging power and a maximum of 10A charging current, the Expert LD 100 charger offers more than sufficient charging power for most applications in a compact design.
On the front there is a built-in XT60 plug where you can easily connect your battery or charging cable reverse polarity protected.
Information about settings and running process can be obtained via the backlit LCD display.
The Expert LD 100 is the perfect multifunction charger and the right choice for most modeller.
Features:
- Compact design
- 100 watts charging power, max. 10A charging current
- Suitable for: LiPo/LiFe/LiIon/LiHV/NiMH/NiCd/Pb
- Easy handling and navigation with four buttons
- Informative LCD display with backlight
- Built-in XT60 connector on the front panel
- 5 batteries profile memory
- Integrated balancer with max. 300mA current
- Various security settings (delta peak sensitivity, auto charge current limit, capacity limit, temperature limit, process time limit, automatic fan)
Technical Specifications:
Input Voltage AC: | 100V -240V |
Max Charge Power: | 100W |
Max Discharge Power: | 10W |
Charge Current Range: | 0.1A - 10.0A |
Discharge Current Range: | 0.1A - 2.0A |
Balancer current: | max. 300mAh |
Cells: LiPo/LiFe/LiIon/LiHV | 2s - 4s |
Cells: NiMH/NiCd | 6s - 8s |
Pb Battery Voltage: | 6V - 12V |
Weight: | 327g |
Dimension: | 115x112x55mm |
Delivery:
1x Expert LD 100 charger
1x Power cord
1x Charging cable Tamiya-connector
1x Charging cable T-connector
1x Manual
Optional Accessories:
SkyRC Temperature Sensor (SK600040)
Robitronic Expert LD 20 Charger NiMh 4-8 cells 2A
Product information "Robitronic Expert LD 20 Charger NiMh 4-8 cells 2A"
Delta Peak charger for 4-8cell NiMH and NiCd batteries with a capacity from 2000mAh up to 6000mAh. The charging time for a 3000mAh batterie is around 90 minutes.
Technical Specifications
Input Voltage: | AC 100-240V, 50/60Hz |
Output Voltage: | DC 4.8-16V |
Supports Battery Type: | 4-8 cell NiMH, NiCd 2000-6000mAh |
Current Output / Power: | = 2A / 20W |
LED Status Standby Charging Finished |
Green (flashing) Red Green |
Output Port: | T-Plug |
RUDDOG 2S Charging Lead 60cm (4/5mm,2mm)(7PIN-XH,XT60)
RUDDOG 2S Charging Lead 60cm (4/5mm,2mm)(7PIN-XH,XT60)
SKY RC S60 DISC.. S60 single AC charger (2-4S up to 6A- 60w)
1. SKYRC S60 Charger
2. Power Cord
3. 18AWG Charging Cable with XT60 Connector
SKY-RC B6 Neo DC charger (200W)
SkyRC's legendary iMax B6 charger was an iconic charger back in 2006, and now SkyRC is proud to introduce the next-generation B6neo. Almost 1/4 the size of its predecessor, smaller than a credit card, B6neo still packs a powerful punch. Unlike the rugged aluminium case of the B6, the B6neo features stunning color schemes in sleek plastic cases. When powered by DC, he can charge up to an impressive 200W, while it can handle up to 80W with USB PD input. This is a significant improvement over the B6, wich can only charge up to 50W on DC and does not support PD input. The B6neo features an XT60 interface as its DC input and a de-facto trendy type-C PD input interface, ensuring greater flexibility and convenience in charging your RC batteries The built-in balance port enables B6neo to discharge faster, allowing it to discharge at up to 24W when used in conjunction with the main port. In contrast, the discharge rate when using the main port alone is limited to just 10W When the balance port is connected, B6neo is a verstile battery checker capable of mesuring cell voltage and the balance state of LiPo, LiHV, LiFe and Lilon battery. The overall voltage and individual cell's voltage will be displayed on the fly to help tell wether the battery is charged or discharged and wether it requires balancing. It will work as a safeguard for batteries as for example LiPo battery is renowed for their high energy density and lightweight properties. Proper care and monitoring are crucial to ensure their safety and longevity. After clicks on the menu, B6neo is ready for your application, offering and optimal voltage of 5-27V with 0.1V increment, adjustable 1-10A current. Short circuit, overload and reverse polarity protection are all included The B6neo uses a proprietary rectifier circuit to efficiently convert DC into safe D/C power for battery charging. And its ontboard MCU precisley controls the charging to minimize power loss to create an incredibly compact form factor. Discover a new colorX interface introduced by B6neo based on simple and textured visuals. The tailor-designed light cyan and green color scheme are for RC charging, it helps you focus on the setting. The Web2.0 responsive menu and well-desiged icons make the operation more suitable for players accustomed to operating smartphones. Input voltage : DC : 10.0 -28.0 V PD3.0/QC : 12.0-20.0 v Input current : DC : 12 A PD : 5 A Max. output power : DC : 200 W PD : 80 W Charge current : 0.2 A-10.0 A Discharge current : Current : 0.1 A-2 A Power : 10 W (+-10%) Balance current : LiPo/LiFe/LiIon/LiHV : Max. 1500mA Size : 70 x 50 x 32 mm Weight : 82 gXT60 & trendy PD input
Discharging multiplied by balance port
Versatile 2in 1 check batteries easily
Charging but also can act as a digital power supply
Rectifier circuit effiency multiplied
Color X easy on the eyes
SkyRC 12-18v Efuel 30a Power Supply, Sk-200013-04 - 200013-04
SkyRC 12-18v Efuel 30a Power Supply, Sk-200013-04
SkyRC B6 Lite Multi Chemistry Charger/d Ischarger, Sk-100151-01 - 100151-01
SkyRC B6 Lite Multi Chemistry Charger/d Ischarger, Sk-100151-01
SkyRC B6 Nano Duo Charger, Sk-100146-02 - 100146-02
SkyRC B6 Nano Duo Charger, Sk-100146-02
SkyRC B6 Nano Multi Chemistry Charger/discharger, Sk-100134-01 - 100134-01
SkyRC B6 Nano Multi Chemistry Charger/discharger, Sk-100134-01
SkyRC B6AC Neo LiPo 1-6s
Product information "SkyRC B6AC Neo LiPo 1-6s"
A beauty on the outside and a true beast on the inside - that's the B6AC neo. A truly compact but extremely powerful charger that retains the basic functions of the original B6AC V2. An impressive charging power of up to 200W DC or 60W AC is contained in this small housing and thanks to the various ports such as XT60 and USB Type-C, this charger can be used almost universally.
What actually makes the B6AC neo better than its predecessor? In direct numbers, the charging and discharging performance has been increased several times. Of course, this saves a lot of time and the new color display and the new software, which is standard on neo chargers, also give the charger a modern touch. The small, pocket-sized device can easily keep up with the digital power supply. All you need is a few clicks in the menu and you're ready to go. It offers an optimal voltage of 2-27V and an adjustable current flow of 1-10A.
The B6AC neo also uses a proprietary rectifier circuit to efficiently convert DC power into safe DC power for charging a battery. And the integrated MCU precisely controls the charging process to minimize power loss. The gallium nitride built into the device also ensures consistent performance while, compared to silicone, it also provides better heat dissipation and lower energy loss.
Reduce your time charging batteries to free up more time for actual fun!
Features:
- 60W AC charging power
- 200W DC charging power
- With 1.77'' color display
- Increased efficiency through the use of gallium nitride (GaN) instead of conventional silicone
- Small format - ideal for every trouser pocket
- Versatile in use thanks to XT60 and USB Type-C ports
- Includes balancer connection for stronger discharge
- Integrated battery tester program
- With PD/QC3.0 fast charging
- Compatible with Charger Master software
Technical Specifications:
Input Voltage AC: | 100 - 240V 50/60Hz |
Input Voltage DC: | 10 - 30V |
Charging Power: | AC max. 60W DC max. 200W USB-C/PD max. 65W |
Discharging Power: | max. 19W (LiPo/6S) |
Charging Current: | 0.2 - 10.0A |
Charging (QC3.0 / PD): | 5V=3A, 9V=3A, 12V=3A, 20V=3.25A, Max. 65W |
Discharging Current: | 0.1 - 2.0A |
Balancing Current: | max. 0.5A |
Trickle Charge: | max. 0.2A & OFF |
Cells: LiPo/LiFe/LiIon/LiHV | 1 - 6S |
Cells: NiMH/NiCd | 1 - 15S |
Cells: Pb | 3S / 6S |
Weight: | 150g |
Dimensions: | 70.6x50.6x46mm |
Delivery:
- 1x B6AC neo charger
- 1x Manual
- 1x AC power cord
SkyRC B6neo Smart Charger grijs LiPo 1-6s 10A 200W
Productinformatie "SkyRC B6neo Smart Charger grey LiPo 1-6s 10A 200W"
SkyRC's B6neo brengt laadplezier met zijn elegante tweekleurige ontwerp in grijs. Of het nu op het circuit of in de hobby is, het onderscheidt zich gewoon van de massa met het rustige kleurenschema en toont de unieke persoonlijkheid van de eigenaar. De B6neo is misschien kleiner dan een creditcard, maar hij is nog steeds extreem krachtig. Met een laadcapaciteit tot 200 W (DC) en tot 80 W met USB PD-ingang zet hij volledig nieuwe normen voor vergelijkbare RC-laders. De elegante kunststof behuizing met zijn aantrekkelijke kleuren is een echte blikvanger!
Functies:
- 200W DC laadvermogen
- 24W ontlaadvermogen
- Zakformaat
- Tot 3x snellere laadtijden dan de B6V2
- Met PD/QC3.0 snel opladen
- Zeer rustig bij ongeveer 48dB
- Compatibel met SkyCharger App en Charger Master
Technische specificaties:
Ingangsspanning: | gelijkstroom: 10V - 28V PD: 12V - 20V |
Laadvermogen: | DC: 200W PD: max. 80W (20V, 5A) |
Ontlaadvermogen: | max. 24W (6S, 4.2V/S) |
Laadstroom: | 0,1 - 20,0 A |
Ontlaadstroom: | 0,1 - 2,0 A |
Balansstroom: | max. 500mA |
Cellen: LiPo/LiFe/LiIon/LiHV | 1 - 6S |
Cellen: NiMH/NiCd | 1 - 15S |
Pb: | 3S / 6S |
Gewicht: | 82g |
Dimensies: | 70x50x32mm |
Levering:
1x B6 NEO lader (grijs)
1x handleiding
SkyRC Balancer Adapter 2-6s HP/PQ Type
Product information "SkyRC Balancer Adapter 2-6s HP/PQ Type"
This is a helpful balancer adaptor used with 2S-6S batteries that come with a HP/PQ port.
Technical Specifications:
Supported Cells: | 2S - 6S |
Battery Port: | HP/PQ |
Charger Port: | XH |
Cable Length: | 103mm |
Dimensions: | 56x29x13mm |
Weight: | 16g |
Delivery:
1x Balancer Board
1x Cable
SkyRC Balancer Adapter 2-6s XH-Type
Product information "SkyRC Balancer Adapter 2-6s XH-Type"
This is a helpful balancer adaptor used with 2S-6S batteries that come with a XH port.
Technical Specifications:
Supported Cells: | 2S - 6S |
Battery Port: | XH |
Charger Port: | XH |
Cable Length: | 103mm |
Dimensions: | 56x29x13mm |
Weight: | 16g |
Delivery:
1x Balancer Board
1x Cable
SkyRC Battery Discharger and Analyzer 40A 380W
No matter what type of battery you want to discharge, factors and distinguishing features such as type, size, chemistry, and the number of cells don't matter. The BD380 can handle a wide variety of batteries up to 30 volts. Inside the robust housing with an XT60 connector for the battery, there is also an effective cooling system to ensure optimal operating temperature. The large color display shows values such as the battery voltage, discharged capacity, and discharge current, among others.
Features
- 4 operating modes: CC (Constant Current), CR (Constant Resistance), CP (Constant Power), CV (Constant Voltage)
- Simple and innovative operation
- Effective cooling system
- Real-time display of battery voltage, discharged capacity, and discharge current
- Efficient testing of battery capacity for optimal battery selection for the next journey
- Controllable via integrated Bluetooth with the SkyCharger app for Android and iOS systems
- Detection of DC-stabilized power supply quality
Operating Voltage: | 3,0 - 30,0V DC | |
Discharge Voltage Range: | 5,9 - 30,0V (main port only) 3,0 - 30,0V (external power supply) |
|
Low Voltage Alarm: | <3,0V | |
High Voltage Alarm: | >max. 30,5V | |
Discharge Power: | max. 380W | |
Discharge Current: | 0,3 - 40,0A | |
Operating Modes: | CC Constant Current | 0,3 - 40,0A |
CR Constant Resistance | 1 - 100 Ohm | |
CP Constant Power | 1 - 380W | |
CV Constant Voltage (Note: Do not connect a battery in this mode) |
max. 180W power (Note: Set the max. current allowed for the current input voltage) |
|
Connector: | XT60 | |
Bluetooth Connection: | Yes (SkyCharger app) | |
Language: | English, French, Spanish, German, Japanese, Chinese | |
Dimensions: | 159,69 x 121,6 x 110mm | |
Weight: | approx. 1100g |
SkyRC BD250 Battery Discharger/Analyzer - 600123-01
SIMPLE, ROBUST AND POWERFUL
Upgraded from BD200, BD250 is not only a powerful discharging device but also a precise measurement tool for battery capacity. It takes the guesswork out of choosing the good-performance battery for your application. BD250 offers a maximum of 250 Watts/35 Amps to discharge your battery and will test virtually any battery type or size, any chemistry cells. It's stylish but small with a high-performance cooling system and uses MOSFETS from the well-known IXYS, to make sure it can discharge at 250 watts continuously.
Specifications
The BD250 is a powerful discharging device that allows the user to discharge a battery at up to 35 amps or 250 watts and also measures and compares the performance of batteries. BD250 allows for the precise measurement of battery capacity and takes the guesswork out of choosing the best battery for your application.
Size and Weight
Dimension: 136.6x104.8x107mm
Weight: 879g
Power
Accepted Voltage Range: 5.40-35.00V
Low Voltage Alert: <5.2V
High Voltage Alert: >35V Max.
Discharge Power: 250W
Discharge
Discharge Current Range: 0.01A-35.00A
Discharge Power: 250W
Display
Current Consumption in Sleep Mode: <100uA
Capacity Display Accuracy: ±3%
Current Display Accuracy:
0.01-10.00A ±60mA
10.00-35.00A ±3%
Voltage Display Accuracy:
5.4-10V <80mV
10-20V <120mV
20-35V <160mV
SKYRC BD350 BATTERY DISCHARGER & ANALYZER
De BD350 is compatibel met de meeste RC-batterijen en werkt met de SkyRC T1000-lader of D200 neo met een ontlaadstroom tot 40A en een ontlaadvermogen van 350W.De BD350 is meer dan alleen een batterijontlader. Bedrijfsspanning: gelijkstroom 5V Ontlaadvermogen: 350 W Ontlaadstroom: 0,1 – 40 A Bescherming tegen oververhitting: >95°C Bedrijfstemperatuur: 0°C ~ 40°C Luchtvochtigheid bij gebruik: 0% ~ 75% Middel: 157 * 105 * 93 mm Gewicht: 1224 gr
Het is een krachtig testinstrument dat de parameters van verschillende batterijen meet, plot en vergelijkt. Het meet nauwkeurig de batterijcapaciteit en prestaties. U hoeft niet meer te raden wanneer u de beste batterij voor RC-racen kiest!
Wanneer de SKY RC-ontlader en -lader samenwerken, kunnen ze het juiste Charger Master3-programma gebruiken om de ontladingscurve van de batterij in realtime te bekijken of te exporteren.
De ontladingscurves van verschillende batterijen kunnen worden uitgezet voor nauwkeurige vergelijking en analyse, zodat defecte batterijen zich nergens kunnen verbergen.
(SKY RC informeert ons dat de BD350 zou moeten werken met opladers van andere merken zoals I-Charger, maar we hebben het zelf niet gecontroleerd).
SkyRC D100neo Ac/dc Multi-function Smart - 100199-01
SkyRC D100neo Ac/dc Multi-function Smart
