Servos feature all-aluminium housings in a 2-tone anodising that is available with silver, red or gold-colour details while the geartrains are made up using high-quality aluminium and steel gears. Japanese Noble potentiometers ensure highest possible precision and an updated PCB supports SSR and SUR modes. The line includes the S15 low-profile and S25 and S35 standard size servos all of which are usable with 6V to 8.4V input.

Specifications:

Power HD Servoarm 16mm + 20mm

Power HD Servoarm 25Z 20mm + 24mm

Specificaties Power HD LF20MG
– Trekkracht 4,8V: 16,5 kg-cm
– Trekkracht 6,6V: 20,0 kg-cm
– Snelheid 4,8V: 0,18 sec
– Snelheid 6,6V: 0,16 sec
– Voltage: 4,8-6,6V
– Gewicht: 60 gr
– Kogellagers: 2
– Motor type: DC motor
– Tandwielen: koper / Aluminium
– Afmetingen: 40,7×20,5×39,5 mm
– Vertanding hevel: 25 tands

PowerHD Black Colour R12S Servo - PHD-R12S

Perfecte servo voor 1/10 Toerwagen 1/10 Buggy M-Chassis of F1 met een prima prijs!

Kenmerken:
Koppel (6,0 V): 9,0 kg-cm (125,0 oz / in) Koppel (7,4 V): 12,0 kg-cm (166,6 oz / in)
Snelheid: 0,07 sec (6,0 V) | 0,06 sec (7,4 V)
Bedrijfsspanning: 6,0 ~ 8,4 DC Volts Gewicht: 41,0 g (1,45 oz)
Type lager: kogellager x 2
Motortype: kernloze motor
Versnellingstype: Titan en aluminium
Bedrijfstemperatuur: -20? ~ 60?
Werkfrequentie: 1520μs / 333hz
Grootte: 41.0 x 20.0 x 26.4 mm (1.61 x 0.79 x 1.04 in)
Servohorn: 25 tands (niet inbegrepen)

PowerHD Coreless High Voltage 1/12 Servo R6 - PHD-R6

Perfect voor 1/12 Auto's zoals XRAY X12, Associated 12R6 etc.

• Torque(6.0V): 6.5 kg-cm (90.26 oz/in)
• Torque(7.4V): 7.5 kg-cm (104.0 oz/in)
• Speed: 0.09 sec (6.0V) │ 0.08 sec (7.4V)
• Operating Voltage：6.0 ~ 8.4 DC Volts
• Weight: 28.5 g (1.01 oz)
• Bearing Type: Ball Bearing x 2
• Motor Type：Coreless Motor
• Gear Type：Copper & Aluminum
• Operating Temperature：-20℃~60℃
• Working frequence：1520μs / 333hz
• Size：35.0 x 15.1 x 29.5 mm ( 1.38 x 0.59 x 1.136 in)

Torque(4.8V): 16.5 kg-cm (229.1 oz/in)
Torque(6.0V): 20.0 kg-cm (277.7 oz/in)
Speed: 0.18 sec (4.8V) │ 0.16 sec (6.6V)
Operating Voltage：4.8 ~ 6.6 DC Volts
Weight: 60 g (2.12 oz)
Bearing Type：Ball Bearing x 2
Motor Type：DC Motor
Gear Type：Copper & Aluminum
Operating Temperature：-20℃~60℃
Working frequence：1520μs / 333hz
Size：40.7 x 20.5 x 39.5 mm ( 1.60 x 0.80 x 1.55 in)

Specificaties Power HD LF-13MG
- Trekkracht 4,8V: 10,5 kg-cm
- Trekkracht 6,6V: 13,0 kg-cm
- Snelheid 4,8V: 0,15 sec.
- Snelheid 6,6V: 0,12 sec
- Voltage: 4,8-6,6V
- Gewicht: 60 gr
- Kogellager: 2x
- Motor type: DC motor
- Tandwielen: Koper / Aluminium
- Frequentie: 1520μs/333hz
- Afmetingen: 40,7 x 20,5 x 39,5 mm

- Trekkracht 4,8V: 3,5 kg-cm
- Trekkracht 6,0V: 4,4 kg-cm
- Snelheid 4,8V: 0,14 sec.
- Snelheid 6,0V: 0,12 sec
- Voltage: 4,8-6,0V
- Gewicht: 43 gr
- Kogellager: 2x
- Motor type: DC motor
- Tandwielen: Kunststof
- Afmetingen: 40,7 x 20,5 x 39,5 mm

This Digital Brushless Low Profile Servo from Power HD with the name “S15” is one of the most valuable servos on the market right now. It has all you need to drive your racecar to the win. The full machined aluminum case makes it very durable and the torque and speed of this servo is really outstanding. For the design of different cars you can choose the S15 with silver, golden or red color accents to look even better in your car! Check out the features of the S15 to see what it`s all about!

Features:

• Torque(6.0V): 11.5 kg-cm
• Torque(7.4V): 15.0 kg-cm
• Speed: 0.072 sec (6.0V) ¦ 0.060 sec (7.4V)
• Operating Voltage:6.0 ~ 8.4 DC Volts
• Weight: 52.0 g
• Bearing Type:Ball
• Bearing x 2
• Motor Type:Digital Brushless Motor
• Gear Type:Titan & Aluminum
• Size:41.0 x 20.0 x 26 mm
• Receiver wire: 80mm length, black, JR Connector
• Servohorn: 25 teeht (not included)

Power HD-1501MG Analog Servo
Koppel (4,8 V): 15,5 kg-cm (215,3 oz / in)
Koppel (6,0 V): 17,0 kg-cm (236,1 oz / in)
Snelheid: 0,16 sec (4,8 V) │ 0,14 sec (6,0 V)
Bedrijfsspanning: 4.8 ~ 6.0 DC Volts
Gewicht: 63,0 g (2,22 oz)
Type lager: kogellager x 2
Motortype: gelijkstroommotor
Versnellingstype: koper
Bedrijfstemperatuur: -20 ℃ ~ 60 ℃
Werkfrequentie: 1520μs / 50hz
Grootte: 40,7 x 20,5 x 39,5 mm (1,60 x 0,81 x 1,56 in)

Ruddog Aluminium Offset Servo Horn 25T (Black)

Das RUDDOG Aluminium Offset Servo Horn überzeugt nicht nur mit seiner Optik, sondern auch durch Qualität. Hergestellt aus 7075-T6 Aluminium bietet es die notwendige Festigkeit um ein präzises Lenkverhalten zu garantieren. Das Servo Horn wird nicht nur über die zentrale Befestigungsschraube montiert, sondern wird mittels einer zusätzlichen Schraube auf das Servo geklemmt. Dies bietet maximale Sicherheit gegen ein Öffnen der Befestigungsschraube und minimiert das Spiel zwischen Servo and Servohorn.

Lochabstand A: 16mm

Lochabstand B: 20mm

Offset: 10.8mm (Länge Rückseite zu Vorderseite)

Materiaal: 7075-T6 Aluminium

Servo-Aufnahme: 25T

Passt bei Servos folgender Hersteller: RUDDOG Products, Savox, Futaba, Highest, Protek, Hitec(neue 25T versionen), Reedy, MKS und vielen weiteren.

Das RUDDOG Aluminium Offset Servo Horn überzeugt nicht nur mit seiner Optik, sondern auch durch Qualität. Hergestellt aus 7075-T6 Aluminium bietet es die notwendige Festigkeit um ein präzises Lenkverhalten zu garantieren. Das Servo Horn wird nicht nur über die zentrale Befestigungsschraube montiert, sondern wird mittels einer zusätzlichen Schraube auf das Servo geklemmt. Dies bietet maximale Sicherheit gegen ein Öffnen der Befestigungsschraube und minimiert das Spiel zwischen Servo and Servohorn.

Lochabstand A: 16mm

Lochabstand B: 20mm

Offset: 10.8mm (Länge Rückseite zu Vorderseite)

Material: 7075-T6 Aluminium

Servo-Aufnahme: 25T

Passt bei Servos folgender Hersteller: RUDDOG Products, Savox, Futaba, Highest, Protek, Hitec(neue 25T versionen), Reedy, MKS und vielen weiteren.

Sanwa Black Servo Extension Cable 50mm

Sanwa Black Servo Pin Housing

SANWA SERVO SRM102

Specifications

The SB-2263MG is a high speed, brushless, low profile servo that features an all black color for a stealth look in RC cars.

Features:

• Metal gear train ensures durability under harsh situations.
• Sleek black design with laser etching and a shorter 200mm black lead wire
• Ideal for 1/10 on road cars requiring a high speed servo

Specifications:

The SB-2263MG is a high speed, brushless, low profile servo that features an all black color for a stealth look in RC cars.

Features:

• Metal gear train ensures durability under harsh situations.
• Sleek black design with laser etching and a shorter 200mm black lead wire
• Ideal for 1/10 on road cars requiring a high speed servo

Specifications:

SRT BH8015 Low Profile (0.055s/13.0kg/7.4V) Brushless Servo

roduct information "SRT Capacitor for BEC 2200uf/10V"

Whenever voltage dips and peaks are a problem, this capacitor with 2200uF/10V is the solution. It improves the voltage stability of the receiver and prevents short-term voltage drops that can be caused, for example, by peak loads from high-quality servos. The stored energy is used to bridge such drops. With reverse currents from servos, however, so-called voltage peaks can sometimes occur. The capacitor can filter out and cushion these high-frequency signals just as easily.

The capacitor is plugged into a free receiver slot.

Servo DL3020 Metal gear Waterproof 20.0kg/0.11sec @6.0V

SRT TRX5 25T 15-19mm Alu Servo Horn (Black)

SRT TRX6 25T 16-20mm Alu Servo Horn (Black)

SRT TRX7 25T 20-24mm Alu Servo Horn (Black)

T-Work's Adjustable 7075-T6 Alum Clamping 25T Servo Horn

T-Work's Adjustable 7075-T6 Alum Clamping 25T Servo Horn +15mm

T-Work's Adjustable 7075-T6 Alum Clamping 25T Servo Horn +5mm

Ultimate Racing Aluminum Steering Servo Horn 28mm w/ Offset 25T

This is a package of 8 anodized M3 Aluminium Servo Washers from Ultimate Racing and are intended for use with any servo. Gain more secure servo mounting with these aluminum servo washers. They preserve the structural integrity of the servo ears. Lightweight and great looking, these washers are the perfect finishing touch for your R/C car. Available in six different anodized colors: blue, orange, black, purple, pink and red.

This is a package of 8 anodized M3 Aluminium Servo Washers from Ultimate Racing and are intended for use with any servo. Gain more secure servo mounting with these aluminum servo washers. They preserve the structural integrity of the servo ears. Lightweight and great looking, these washers are the perfect finishing touch for your R/C car. Available in six different anodized colors: blue, orange, black, purple, pink and red.

YellowRC 20kg Digital Waterproof Servo Trx2075 Replacement + Free Extension Wire
